ScanAfia XL Nursing Bed


ScanAfia XL Nursing Bed

A quality new arrival for home and home-like care

Main features:

1. Mattress base width 120 cm for increased comfort and safety

2. Maximum load (SWL) 285 kg enables care of larger patients

3. Impressive height adjustment range improves patient independence and carer comfort


About

The special sized ScanAfia XL nursing bed has been designed with larger and heavier patients in mind. The bed is particularly suitable for nursing homes, where the average size of patients has increased. The special sized bed is 120 cm wide, with a maximum patient weight of 250 kg.

The ScanAfia nursing bed can be combined with our range of tables and chairs, creating a harmonious décor without compromising functionality. The solid white oak bed ends give the bed a longer life cycle than standard beds. Our high quality epoxy coating also contributes to the long lifespan of our beds – we are the only manufacturer to abrasive blast steel components before painting.



The bed features a safe 24V low voltage electrical system, and its electrical motors and control units are splash resistant. The beds can be fitted with a separate nurse panel as an optional extra, allowing the functions of the bed to be restricted to nurse control only if necessary. The design of the bed is based on the new 60601-1-52 nursing bed standard and the range has been impartially tested in an independent laboratory.
The bed has been fire tested according to SL1.

The large double wheels make the bed easy to manoeuvre yet extremely sturdy when locked in position.

The Range

ScanAfia XL

4-part bed section 118x205 cm, with electric height, back section, thigh section and calf section adjustment.


Technical standard features:

  • Safe Working Load (SWL) 285 kg
  • Wide, four-part bed section, width 118 cm
  • Solid wood bed ends (white-oak)
  • Double-locked wooden sides with a locking button (pair)
  • Electric height, back section, thigh section and calf section adjustment with hand control
  • Anti-Trendelenburg adjustment
  • Emergency lowering of back section
  • Centrally lockable twin castors Ø150 mm with directional wheel
  • Removable base plates
  • Integrated fixings for 2 lifting poles and IV-pole
  • Fixings in the base plate for restraining straps (holes)
TECHNICAL DATA
Overall width with rails 130 cm
Overall length 217 cm
Height adjustment range Min. 32 cm - max. 82 cm (depending on the castor size and type)
Recommended mattress size 205 x 118 x 13 cm
Total weight (inc. rails) 145 kg
Castors Ø150 mm twin castors
Safe Working Load (SWL) 285 kg
Electrical system 24V
Back section adjustment 70°
Thigh section adjustment 30°
Calf section adjustment 11°
Anti-Trendelenburg 20°
CE–marked Yes
Warranty 2 years
Country of Manufacture Finland
